    8 Inch Dough Rolling Tortilla Production Line 7200 Pcs Per Hour

    8inch7200 Pce Per Hour Tortilla Production Line


    8inch 7200 pce per hour tortilla production line


    8inch7200 pce per hour tortilla production line cosists of dough rolling,dough ball forming,pressing,oven,cooling and stacking deovices.

    Components
    Machine NameSize(mm)PowerDescription
    Dough Conveyor1100X910X10700.48KWIt can convey 2-3 rows dough ball with adjustable distance.
    Presser2980X1345X210038.24KWCycles in a minute: 20 - 35 times?
    Capacity for each size:
    8200 pcs/hour for 20cm (8”)
    3600 pcs/hour for 30cm (12”)
    Frame: stainless steel, heavy duty
    Working temperature: 0 - 300℃
    Servo tracking continuous pressing
    Teflon belt runs at constant speed
    Size of press heating plate: 72x72cm
    9 pcs /time for 15cm and 25cm (6" and 8”)
    4 pcs /time for 25cm and 30cm (10" and 12”)
    The pressing time is closely related according to the size of the tortilla and the temperature of heating plate. The temperature can be controlled separately, and the temperature error is ±3℃. The machine frame is made of stainless steel, and the pressing area is heavy duty steel plate with painting treatment
    Oven5150X1650X15052.37KWThe oven has three layers in total. The upper two layers are stainless steel heating chain plate, and the lowest layer is stainless steel conveyor mesh belt. Each layer of heating chain plate is equipped with 4 sets of gas heating system, which can be controlled separately. The heating chain plate and bottom mesh belt can be adjusted to meet the baking time which is required for different tortillas. It is equipped with electronic ignition system, flame detection and alarm system. The machine frame is made of stainless steel.
    Isolation system: critical parts covered with stone wool
    Frame : stainless steel, heavy duty
    Drive system : by motor
    Continuous system: yes
    Baking time: 30 - 90 seconds
    Cooling line8700X1350X14901.5KW5-layer and 6-metre high cooling system, each layer can individually control the conveying speed, the top is equipped with cooling fan.
    Electric cabinet700X550X18000.15KW
    Chiller840X620X10603.6KW
    Counter & Stacker3275X1400X10501.12KWMultiple cylinders are combined with the detection and counting system to control the number of stacked tortillas, the stacked quantity can be adjusted.
