Apple Pomace Pectin Production Line 500kg Per Hour

Ask Lasest Price
Brand Name :	sss
Model Number :	customzied
Price :	usd4,085,000
Payment Terms :	L/C, T/T
Supply Ability :	5sets/y
Delivery Time :	120

Add to Cart

Product Details
Company Profile

Apple Pomace Pectin Production Line 500kg Per Hour

500kg Per Hour Apple Pomace Pectin Production Line Fruit Processing Line

201	Alcohol storage tank	Ø Volume:10000L Ø Double-layer insulation, inner wall 3mm, middle 50mm rock wool insulation, outsourcing 1.5mm, manhole, cleaning ball, thermometer, import and export, etc.
202	Material pump	Ø Capacity: 10T/h Ø Head:24m Ø Power 2.2KW
203	Chromatography column system	Ø Volume:800L Ø Single column quantity 10, Ø 304 stainless steel material, sight glass, Ø PLC automatic control
204	Decanter Separator	Ø Capacity: 5T/h Ø Three-phase separation structure (liquid phase, solid phase), Ø the diameter of the turning stock is 450mm, the rotation speed is 3600rpm, and the power is 52KW
205	Alcohol collection tank	Ø Volume:500L Ø SS304 material
206	Material pump	Ø Capacity: 3T/h Ø Head:24m Ø Power 2.2KW
207	Material storage tank	Ø Volume:500L Ø SS304 material
208	Screw pump	Ø Capacity: 1T/h; Ø Output pressure:0.6MPA Ø Power: 1.1kw;
209	Vacuum low temperature belt dryer	Ø 120㎡ vacuum belt dryer host, Ø feeding system, discharging system, heating system, vacuum system, cooling system, deviation correction system, CIP in-place cleaning system, electrical control system, material transmission system
210	Big bag packing machine	Ø Output:1T/h Ø 304 stainless steel material, Ø including lifting conveyor, weighing system, sealing device, etc.
211	Electrical control cabinet	Ø Siemens PLC, touch screen, Ø Schneider Omron low-voltage components, Ø stainless steel control cabinet
212	Diluted alcohol storage tank	Ø Volume:10000L Ø Double-layer insulation, inner wall 3mm, middle 50mm rock wool insulation, outsourcing 1.5mm, manhole, cleaning ball, thermometer, import and export, etc.
213	Material pump	Ø Capacity: 10T/h Ø Head:24m Ø Power 2.2KW
214	Alcohol recovery tower	Ø capacity:300L/h Ø Including distillation kettle, distillation tower, metering tank, condenser, cooler, recovery tank, discharge pump, PLC automatic control system
215	Recycled Alcohol Storage Tank	Ø Volume:10000L Ø Double-layer insulation, inner wall 3mm, middle 50mm rock wool insulation, outsourcing 1.5mm, manhole, cleaning ball, thermometer, import and export, etc.
216	Material pump	Ø Capacity: 10T/h Ø Head:24m Ø Power 2.2KW

Company Profile

SSS Food Machinery Technology Co., LTD is a leading supplier of food processing equipment in China.We are able to provide complete turnkey project solution for intelligent processing equipment.We are mainly specialized in fruit and vegetables processing line for puree,juice,jam,dried fruit, powder,fruit wine & vinegar,fermented beverage,ect .Also the related stand-along equipment with superior quality,competitive price and professional service.SSS has a complete team from R&D design, production, quality inspection,process guidance, with more than 20 years’ professional experience in this field.
